AC CONTACTOR STC2-L
We provide free samples, you just need to cover the shipping cost. we sincerely look forward to cooperating with you for mutual benefit, and please contact us for any other questions.
Product Specification:
| Type | STC2-L | STC2-L | STC2-L | STC2-L | STC2-L | STC2-L | STC2-L | STC2-L | STC2-L | STC2-L | |
| 9 | 12 | 18 | 25 | 32 | 40 | 50 | 63 | 80 | 95 | ||
| 60 | |||||||||||
| Rated insulatio voltage | 660 | 660 | 660 | 660 | 660 | 660 | 660 | 660 | 660 | 660 | |
| conventional thermal | 20 | 24 | 32 | 40 | 50 | 60 | 75 | 80 | 110 | 125 | |
| current | |||||||||||
| Rated operational | 9 | 12 | 16 | 25 | 32 | 40 | 50 | 63 | 80 | 95 | |
| current | |||||||||||
| controlled | 220V | 2.2 | 3 | 4 | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 25 |
| power(kw) | 380V | 4 | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 45 |
| 415V | 4 | 5.5 | 9 | 11 | 15 | 22 | 35 | 37 | 45 | 45 | |
| 440V | 4 | 5.5 | 9 | 11 | 15 | 22 | 30 | 37 | 45 | 45 | |
| 660V | 5.5 | 7.5 | 10 | 15 | 18.5 | 30 | 33 | 37 | 45 | 45 | |
| Note | The installation of the | The installation of the | |||||||||
| relays can use two screws | relays can three | ||||||||||
| and also use the 35mm | screws and also use the | ||||||||||
| installation rail | 75mm or 35mm installation | ||||||||||
| rail | |||||||||||
Product Description
AC CONTACTOR STC2-L is a type of contactor used for controlling AC circuits. It has a wide rated current range, making it suitable for AC circuits of different powers and voltages. The STC2-L contactor uses a DC control electromagnetic coil, allowing for quick and reliable switching operations.
The STC2-L contactor is highly reliable and durable, capable of working stably in harsh environments. It is manufactured using high-quality materials with good insulation and high-temperature resistance, ensuring stability during long-term high-load operations.
With a compact design, the STC2-L contactor is easy to install and operate. It is widely used in industrial control systems, power systems, lighting systems, and other fields to effectively control circuit switching and protect equipment for safe operation.
In conclusion, the AC CONTACTOR STC2-L is a high-performance, reliable contactor that can meet the control requirements of various AC circuits. It is a commonly used electrical component in the industrial sector.
